Kubernetes Autoscaling: How to use the Kubernetes Autoscaler

Kubernetes Autoscaling

Imagine a situation where when user load increases or decreases on an application, there is no way for the application to scale out or in its resources as required. Such an application probably wouldn’t survive in today’s market thanks to Kubernetes Autoscaling, which can easily overcome such a situation with its different scaling mechanisms.

Kubernetes Autoscaling mechanisms help scale in and out pods and nodes as required. There are three different methods supported by Kubernetes Autoscaling.

  1. Horizontal Pod Autoscaler (HPA)
  2. Vertical Pod Autoscaler (VPA)
  3. Cluster Autoscaler (CA)

In this article, we will be taking a look at the different methods of Kubernetes Autoscaling that help with the automated process of scaling resources required by the application.

Table of contents

What is Kubernetes Autoscaling?

Many administration chores can be automated with Kubernetes, including provisioning and scaling. Instead of assigning resources manually, you can automate procedures that save time, allowing you to respond quickly to demand spikes and save money by scaling down when resources aren’t needed. This can be used in conjunction with the Cluster Autoscaler, which only allocates necessary resources.

Using autoscaling makes you more likely to operate with optimal resource utilization and cloud spending. Without autoscaling, you’re manually provisioning (and later scaling down) resources every time conditions change.

By dynamically scaling resources up and down in response to demand, Kubernetes Autoscaling helps optimize resource utilization and expenditures.
Before we jump into practical notions, let’s take a look at the theory behind each  Kubernetes Autoscaling feature.

The Kubernetes Horizontal Pod Autoscaler

The Kubernetes Horizontal Pod Autoscaler in Kubernetes changes the workload resource,  such as a Deployment,  StatefulSet or other similar resources, and automatically scales the workload to meet demand. Horizontal scaling refers to the deployment of extra pods in the Kubernetes Cluster in response to a growing load

Moreover, the Horizontal Pod Autoscaler automatically orders the workload resource to scale back down if the load drops and the number of pods exceeds the defined minimum. This allows your applications to scale out in response to growing demand and scale in when resources aren’t required, freeing up nodes for other applications. For example, if a Deployment is running 1 pod and you want the number of pods to vary between 1 and 4 depending on resource utilization, you can create an HPA that will scale the number of pods controlled by the Deployment.

Kubernetes Horizontal Pod Autoscaler diagram

It is to be noted that Horizontal Pod autoscaling is not compatible with unscalable workloads,  such as DaemonSets. Daemonsets work on a “one pod per node” basis, and therefore, they cannot have replicas, which is why HPA is not compatible with Daemonsets.

The Kubernetes Vertical Pod Autoscaler

The Vertical Pod Autoscaler is an autoscaling tool that can be used to resize pods for optimal CPU and memory resources. You can use Vertical Pod autoscaling to provide recommended values for CPU  and memory requests and limits or to automatically update the values instead of having to set up up-to-date CPU and memory requests and limits for the containers in your pods.

The Kubernetes Vertical Pod Autoscaler automatically increases your pods’ CPU and memory reservations to help you “right-size” your applications. This can increase cluster resource utilization while also freeing CPU and memory for other pods.

Here are a few of the benefits that the VPA provides:

  1. Seeing as they only consume what they require, pods make efficient use of cluster nodes.
  2. You don’t need to perform time-consuming benchmarking procedures to identify optimal CPU and memory requirements values.
  3. Maintenance time is decreased, seeing as the VPA can modify CPU and memory requests over time without any need for intervention on your part.

Kubernetes Cluster Autoscaler

Based on the presence of pending pods and node utilization data, the Kubernetes Autoscaler increases or decreases the size of a Kubernetes cluster by adding or removing nodes.

When the Kubernetes Autoscaler identifies pending pods that cannot be scheduled, potentially resulting in resource constraints, it adds nodes to the cluster. Moreover, when the utilization of a node falls below a particular threshold set by the cluster administrator, it removes nodes from the cluster allowing for all the pods to have a place to run and avoiding unnecessary nodes.

Kubernetes Cluster Autoscaling diagram

Worker Nodes

Kubernetes-as-a-Service is managed by EKS. That said, this mostly refers to the Kubernetes control plane. You must still provide compute nodes to your EKS Cluster in order for the pods to be deployed. There are two ways of creating worker nodes for your EKS Cluster.

Self-Managed Nodes:
With this option, you create, manage and administer your own worker nodes, which gives you more control over your servers.

EKS Managed Nodes:
With this option, you don’t need to manage the nodes in the EKS Kubernetes Cluster. All you need to do is specify configurations and EKS takes care of the rest. Further in this article, we will show you how to use EKS Managed Nodes to create worker nodes for the cluster.

Blue-Green and Rolling Updates within Kubernetes

One of the most important things to know in this regard is how to reliably launch the next version of the application when one is already running. How can the present pods be replaced without disturbing traffic?

Kubernetes supports a variety of deployment options. Below, we present to you two options that provide for secure deployment while retaining the ability to backtrack, if necessary.

Blue-Green Deployment

How does Blue-Green deployment work in Kubernetes?

  1. Let’s assume you have the first version of a software called my-app (v1), which is currently running in blue.

  2. You have a new version (v2) that is ready to deploy. You, therefore, need to establish a new environment, which is known as a green environment. Users are unaware of the change because the blue environment continues to function normally. They won’t notice anything until you change the traffic from blue to green.

  3. Basically, both versions exist at the same time, but the Kubernetes service is still pointing to the blue version, therefore most users won’t notice the change. Various types of tests can be performed on the new version without disturbing existing users.

  4. When you’re ready,  the Kubernetes service is switched to point to the new version (v2) and without any downtime, all live users can now access the new version of the software.
    1. If the new version (v2) performs as planned, the old version (v1) will be discarded.The new version will become the current version  and the Kubernetes service will continue to function normally.
    2. If problems arise  with the new version (v2), the Kubernetes service will be reverted to the previous version (v1), having a very negligible effect on users. The new version will be obliterated, and everything will return to its previous state, a.k.a the old version (v1).
Blue-Green Deployment diagram

Rolling Update

The ability to execute rolling updates is one of the main advantages of using a Deployment to govern your pods. Rolling updates allow you to progressively update the configuration of your pods, and Deployments give you optimal control over the process.
The update strategy is the most critical setting when it comes to configuring rolling updates.

Spec.strategy.type offers two possible values in your Deployment manifest:

  1. Rolling Update: New pods are gradually introduced, and old pods are gradually phased out.
  2. Recreate: Before any new pods are inserted, all old pods are terminated.

Other Autoscalers: Karpenter

Karpenter is an open-source, customizable and high-performing Kubernetes Cluster Autoscaler built on AWS. It improves application availability and cluster efficiency by quickly deploying the appropriate compute resources in response to a changing application load.

Karpenter also offers just-in-time computing resources to fulfill your application’s requirements and will soon provide a cluster compute resource footprint, which will decrease costs and increase performance. Karpenter monitors the aggregate resource requests of unscheduled pods and decides whether to deploy new nodes or terminate existing ones to reduce scheduling delays and infrastructure expenses.

Kubernetes Keda – Event-Driven Autoscaling

KEDA (Kubernetes-based Event-driven Autoscaling) is an open-source component created by Microsoft and Red Hat, which allows Kubernetes workload to benefit from an event-driven architecture style

KEDA horizontally scales a Kubernetes Deployment or Job. It is based on the Kubernetes Horizontal Pod Autoscaler and allows users to specify autoscaling criteria based on information from any event source, including a Kafka topic latency and metrics acquired from a Prometheus query. This feature allows you to pick from a list of pre-defined triggers that serve as a source of events and metrics when autoscaling a Deployment or a Job.

Kubernetes Autoscaling

Before we dive into the different Kubernetes Autoscaling mechanisms on a practical level, let’s create a Kubernetes Cluster on AWS using the EKS managed nodes as our playground.

Create an EKS Cluster

1. Go to EKS and click on “Add cluster” → “Create” options.

Create an EKS Cluster step 1

2. The configuration screen below should appear on your device. Provide a name to the cluster, choose the Version, Service Role and click on the “Next” button.

Create an EKS Cluster step 2

3. Next, select a VPC, Subnets, and a Security Group.

Create an EKS Cluster step 3

4. Keep the Cluster endpoint on “Public” so that it can be accessed from your machine.  Select the latest versions of Networking add-ons and click on the “Next” button.

Create an EKS Cluster step 4

5. Click on the “Next” button and enable logging if required.

Create an EKS Cluster step 5

6. Review the configuration and click on the “Create” button to create the EKC control plane.

Create an EKS Cluster step 6

7. Verify the details of the cluster. Once the cluster is set to “Active” you can access it.

Create an EKS Cluster step 7

Export AWS Keys on the CLI

Before you access the cluster, you need to configure your CLI in order to connect to your AWS account. The easiest way to do this is to export your AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY. You need to have these keys handy at all times. In this case, the keys must belong to the AWS user and the user must have the required permissions. For the sake of the demo, you can use the root account’s keys, however we do not recommend using the root user.

  1. Export your keys
    1. export AWS_ACCESS_KEY_ID=<YOUR_AWS_ACCESS_KEY_ID>
    2. export AWS_SECRET_ACCESS_KEY=<YOUR_AWS_SECRET_ACCESS_KEY>

  2. Check the details of the IAM user whose keys are being used to request the operation.
    1. aws sts get-caller-identity

Update Kubeconfig File

You are now just one step away from accessing the cluster from the CLI. In order to do this, you must first configure kubectl, which will allow you to connect to the Amazon EKS cluster you just created. The “aws” command must also be available on your local machine.

  1. Check the version of “aws” command that you have.
    1. aws –version

  2. Create a configuration with a pre-populated server and certificate authority data values for your cluster, i.e. download the kubeconfig file of the cluster.
    1. aws eks update-kubeconfig –region ap-south-1 –name test-eks-cluster

  3. Check the Kubernetes Service to verify whether you can access the cluster. To confirm your access, you can try to get nodes or other resources.
    1. kubectl get svc
    2. kubectl get nodes
Update Kubeconfig File

Create an Identity Provider

EKS cluster has an OpenID Connect issuer URL associated with it. An IAM OIDC provider must exist in order for your cluster to be able to use IAM roles for service accounts.

1. To create an IAM OIDC provider, copy the OpenID Connect provider URL from the EKS Cluster.

Create an Identity Provider step 1

2. Go to IAM –> Identity Provider and click on the “Add provider” button.

Create an Identity Provider step 2

3. Select the “OpenID Connect” option and paste the “OpenID Connect provider URL” copied above in the “Provider URL” textbox. Next, click on the “Get thumbprint” button and add “sts.amazonaws.com” in the “Audience” textbox. Finally, click on the “Add provider” button.

Create an Identity Provider step 3

4. Once you have added the provider, you should see the following configuration on your screen. Copy the “ARN” from this screen before you move onto the next step.

Create an Identity Provider step 4

Create an IAM Role

In order to deploy Amazon EC2 nodes to the cluster, you will need an IAM role.

1. Create an IAM Role “test-eks-ng-role” with AmazonEKSWorkerNodePolicy, AmazonEC2ContainerRegistryReadOnly, and SystemAdministrator permissions.

Create an IAM Role step 1

2. Add the following trust relationships to the IAM Role.

{
    “Version”: “2012-10-17”,
    “Statement”: [
        {
            “Effect”: “Allow”,
            “Principal”: {
                “Service”: “ec2.amazonaws.com”
            },
            “Action”: “sts:AssumeRole”
        },
        {
            “Effect”: “Allow”,
            “Principal”: {
                “Federated”: “<REPLACE-THIS-WITH-THE-ARN-OF-THE-IDENTITY-PROVIDER-WE-CREATED-IN-THE-ABOVE-STEP>”
            },
            “Action”: “sts:AssumeRoleWithWebIdentity”
        }
    ]
}
Create an IAM Role step 2

Create an EKS Managed Node Group

Now, let’s create an EKS managed node group.

1. First off, go to the EKS control plane that you created, click on the “Computer” tab and then click on the “Add Node Group” button.

Create an EKS Managed Node Group step 1

2. Next, provide a name for the Node Group and choose an IAM Role with sufficient permissions for the nodes to perform the required operations. For the sake of the demo, you can create a Role with full administrative access.

Create an EKS Managed Node Group step 2

3. The other configurations on this page are optional. Click on the “Next” button to proceed.

Create an EKS Managed Node Group step 3

4. Now, choose the AMI,  Capacity and Instance settings for the nodes, as well as the disk size, minimum, maximum, and the desired number of Instances in the Node Group.

Create an EKS Managed Node Group step 4

5. Click on the “Next” button.

Create an EKS Managed Node Group step 5

6. Specify the Subnets and click on “Next”.

Create an EKS Managed Node Group step 6

7. Review the configurations and click on “Create.”

Create an EKS Managed Node Group step 6

8. Once the node is up and running (after 2-3 minutes), you can get the status of the node using kubectl command.
a. kubectl get nodes

Create an EKS Managed Node Group step 8

9. You can also check the default pods using the following commands:
a. kubectl get pods
b. kubectl get pods -A

Create an EKS Managed Node Group step 9

Install Metric Server

At this point, you should have a Kubernetes Cluster with one node. Before you set up Kubernetes Autoscaling, you need to add a Metric Server to the Cluster.

The Kubernetes Metrics Server is a resource consumption data aggregator which isn’t installed by default in Amazon EKS clusters. Other Kubernetes add-ons typically use the Metrics Server.

The Kubernetes Metrics Server collects resource metrics from each worker node’s kubelet and presents them to the Kubernetes API server via the Kubernetes Metrics API.

The Metric Server can be installed using the following command:

1. kubectl apply -f
https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml

Install Metric Server step 1

Set up an HPA

You are now ready to implement your first Kubernetes Autoscaling mechanism.

  1. First off, create a test-hpa.yaml file with the following content, which contains the definition of a Deployment and Service.
    1. vim test-hpa.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: php-apache-test-hpa
spec:
  selector:
    matchLabels:
      run: php-apache-test-hpa
  replicas: 1
  template:
    metadata:
      labels:
        run: php-apache-test-hpa
    spec:
      containers:
      – name: php-apache-test-hpa
        image: k8s.gcr.io/hpa-example
        ports:
        – containerPort: 80
        resources:
          limits:
            cpu: 200m
          requests:
            cpu: 100m

apiVersion: v1
kind: Service
metadata:
  name: php-apache-test-hpa
  labels:
    run: php-apache-test-hpa
spec:
  ports:
  – port: 80
  selector:
    run: php-apache-test-hpa

2. Execute the following command to create a Deployment and Service:
a. kubectl apply -f test-hpa.yaml

3. Review the Deployment and Service created from the above object file.
a. kubectl get deployments
b. kubectl get pods
c. kubectl get svc

Set up an HPA step 1

4. Now you can create an HPA that can help with Kubernetes Pod Autoscaling by decreasing or increasing the number of pods based on resource consumption. The following “kubectl autoscale” will create an HPA which increases the number of pods if CPU resource consumption increases by more than 50%.
a. kubectl get hpa
b. kubectl autoscale deployment php-apache-test-hpa –cpu-percent=50 –min=1 –max=10
c. kubectl get hpa
d. kubectl get pods

Set up an HPA step 4

5. As you can see, Deployment currently has only one replica.

Set up an HPA step 5

6. Check the current number of pods and create a load generator that will increase the resource consumption of the Deployment by hitting the service, thus helping with the Kubernetes Pod Autoscaling.
a. kubectl get pods
b. kubectl run load-generator –image=busybox –restart=Never — /bin/sh -c “while sleep 0.01; do wget -q -O- http://php-apache-test-hpa; done”

7. If you check the number of pods, you will notice that the pod count has not yet increased.Wait a few seconds for the load generator to start.
a. kubectl get pods
b. kubectl get hpa
c. kubectl get pods
d. kubectl get hpa

Set up an HPA step 7

8. If you check the pods again, you should notice that the pod count has increased and the Kubernetes Pod Autoscaling has taken place.  The HPA works by increasing the number of pods in response to an increase in resource consumption.
a. kubectl get pods
b. kubectl get hpa

Set up an HPA step 8

9. You can describe the HPA object in order to verify the scaling details.
a. kubectl describe hpa php-apache-test-hpa

Set up an HPA step 9

10. You can now delete all of the resources created as part of the HPA.

a. Get the deployment, Service and HPA
i. kubectl get deployment
ii. kubectl get svc
iii. kubectl get hpa

b. Delete the HPA, Service, and Deployment.
i. kubectl delete hpa php-apache-test-hpa
ii. kubectl delete svc php-apache-test-hpa
iii. kubectl delete deployment php-apache-test-hpa

c. Confirm the deletion.
i. kubectl get deployment
ii. kubectl get svc
iii. kubectl get hpa

d. Delete the load generator pod.
i. kubectl delete pod load-generator

Set up an HPA step 10

Set up a VPA

VPA is our second Kubernetes Autoscaling method. Before you can set up a VPA, you need to first need to install VPA in order for the Cluster to be able to recommend and set resource requests for your pods. Multiple Kubectl commands the installation issues to the Kubernetes Cluster which inserts the configuration and deploys the required pods in the kube-system namespace.

  1. Execute the following commands to install the VPA:
    1. git clone https://github.com/kubernetes/autoscaler.git
    2. cd autoscaler
    3. cd vertical-pod-autoscaler
    4. git checkout vpa-release-0.8
    5. ./hack/vpa-up.sh

Note: You will get the following error codes if you do not switch to a vpa-release-0.8 branch or if the openssl version is not 1.1.1 or higher and does not support -addext option. For additional details, please refer to the Github repository here.

Set up a VPA step 1

2. Now, create a test-vpa-deployment.yaml file with the following content. By way of example, we are defining CPU and Memory requests for the pods.
a. vim test-vpa-deployment.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: test-vpa-deployment
  labels:
    app: sample-app
spec:
  replicas: 2
  selector:
    matchLabels:
      app: sample-app
  template:
    metadata:
      labels:
        app: sample-app
    spec:
      containers:
        – name: test-vpa-container
          image: k8s.gcr.io/ubuntu-slim:0.1
          resources:
            requests:
              cpu: 100m
              memory: 50Mi
          command: [“/bin/sh”]
          args:
            – “-c”
            – “while true; do timeout 0.5s yes >/dev/null; sleep 0.5s; done”

3. You now need a Vertical Pod Autoscaler resource for the Deployment to automatically compute resource requirements. Let’s create test-vpa-object.yaml with the following content.
a. vim test-vpa-object.yaml

apiVersion: autoscaling.k8s.io/v1beta2
kind: VerticalPodAutoscaler
metadata:
  name: test-vpa
spec:
  targetRef:
    apiVersion: “apps/v1”
    kind:       Deployment
    name:       test-vpa-deployment
  updatePolicy:
    updateMode: “Auto”

4. Check the existing pods and create a Deployment using the following commands.
a. kubectl get pods
b. kubectl apply -f test-vpa-deployment.yaml

5. Check the existing pods and create a VPA resource using the following commands.
a. kubectl get pods
b. kubectl apply -f test-vpa-object.yaml
c. kubectl get vpa

Set up a VPA step 5

6. Once the VPA resource is created, it can set the requests automatically based on usage for each pod.

7. Describe the VPA resource using the following command to see recommendations.
a. kubectl describe vpa nginx-deployment-vpa

Set up a VPA step 7

The screenshot above shows the recommendations given by the VPA object.

8. You can also check the Kubernetes Events w.r.t. the VPA.
a. kubectl get events | grep VPA
b. kubectl get pods

Set up a VPA step 8

9. You can now delete all of the resources created as part of the VPA.
a. kubectl delete -f test-vpa-object.yaml
b. ubectl delete -f test-vpa-deployment.yaml

Set up a VPA step 9

Set up a Kubernetes Cluster Autoscaler

Install Kubernetes Cluster Autoscaler

1. The first step to setting up the Kubernetes Autoscaler is to download the Cluster Autoscaler YAML file.
a. curl -o cluster-autoscaler-autodiscover.yaml https://raw.githubusercontent.com/kubernetes/autoscaler/master/cluster-autoscaler/cloudprovider/aws/examples/cluster-autoscaler-autodiscover.yaml

2. Once the file is downloaded, modify it and replace <YOUR CLUSTER NAME> with the cluster name in the file.
a. vim cluster-autoscaler-autodiscover.yaml

3. You can now apply the YAML file to set up the Kubernetes Autoscaler.
a. kubectl apply -f cluster-autoscaler-autodiscover.yaml

3. You can now apply the YAML file to set up the Kubernetes Autoscaler.
a. kubectl apply -f cluster-autoscaler-autodiscover.yaml

Set up a Kubernetes Cluster Autoscaler step 3

4. When performing the step above,a Service Account will be created. You must annotate this cluster-autoscaler Service Account with the ARN from the IAM Role “test-eks-ng-role” that was previously created. Replace the <example values> with your own values.
a. kubectl annotate serviceaccount cluster-autoscaler -n kube-system eks.amazonaws.com/role-arn=<ARN-OF-test-eks-ng-role-Role>

Set up a Kubernetes Cluster Autoscaler step 4

5. The next step is to patch the Deployment in order to add the cluster-autoscaler.kubernetes.io/safe-to-evict annotation to the Cluster Autoscaler pods with the following command. This Deployment was created when you deployed the autoscaler.
a. kubectl patch deployment cluster-autoscaler -n kube-system -p ‘{“spec”:{“template”:{“metadata”:{“annotations”:{“cluster-autoscaler.kubernetes.io/safe-to-evict”: “false”}}}}}’

Set up a Kubernetes Cluster Autoscaler step 5
  1. Now, edit the Kubernetes Autoscaler Deployment and add the following options under the command section in the spec as shown in the following screenshot.
  • –balance-similar-node-groups
  • –skip-nodes-with-system-pods=false

a. kubectl -n kube-system edit deployment.apps/cluster-autoscaler

Set up a Kubernetes Cluster Autoscaler step 6

7. In a web browser, go to the Kubernetes Autoscaler releases page on GitHub and look for the newest Kubernetes Autoscaler version that matches your cluster’s Kubernetes major and minor versions. For example, if your cluster’s Kubernetes version is 1.21, find the newest Kubernetes Autoscaler release starting with 1.21. write down the semantic version number (1.21.n) for the release, which will be required for the next step.

8. With the following command, set the Kubernetes Autoscaler image tag to the version you selected in the previous step. In this case, it’s v1.21.2. It will be different for you if your control plane has a different version.
a. kubectl set image deployment cluster-autoscaler -n kube-system cluster-autoscaler=k8s.gcr.io/autoscaling/cluster-autoscaler:v1.21.2

Set up a Kubernetes Cluster Autoscaler step 8

9. Check the logs of the Kubernetes Cluster Autoscaler.
a. kubectl -n kube-system logs -f deployment.apps/cluster-autoscaler

Set up a Kubernetes Cluster Autoscaler step 9

You will notice the error in the screenshot above if you haven’t set up the Identity Provider, as shown in the “Create an Identity Provider” step.

10. In this case, you can delete the Kubernetes Cluster Autoscaler pod once you have added the Identity Provider.
a. kubectl get pods -n kube-system | grep auto
b. kubectl delete pod cluster-autoscaler-866c8566d7-x9b6k -n kube-system
c. ubectl get pods -n kube-system | grep auto

Set up a Kubernetes Cluster Autoscaler step 10

11. Again, you will see the error code in the following screenshot if you haven’t set up the Trust Relationships in the IAM Role as shown in the “Create an IAM Role” step.

Set up a Kubernetes Cluster Autoscaler step 11

12. In this case, you can delete the Kubernetes Autoscaler pod once the Trust Relationships have been added to the IAM Role.
a. ubectl -n kube-system logs -f deployment.apps/cluster-autoscaler
b. kubectl get pods -n kube-system | grep auto
c. kubectl delete pod cluster-autoscaler-866c8566d7-4q97h -n kube-system

13. Once you have configured the Identity Provider and Trust Relationships correctly, you shouldn’t see any errors in the Kubernetes Autoscaler logs. The logs should be as follows:
a. kubectl -n kube-system logs -f deployment.apps/cluster-autoscaler

Set up a Kubernetes Cluster Autoscaler step 13

14. Before testing the Kubernetes Cluster Autoscaling to scale the nodes as required, check the current pods and nodes for any issues.
a. kubectl get pods -A
b. kubectl get nodes

Set up a Kubernetes Cluster Autoscaler step 14

Test the Kubernetes Cluster Autoscaler

You can now test the Cluster Autoscaling.

1. Create a test-auto-scaling.yaml file with the following content:
a. vim test-auto-scaling.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: test-node-auto-scaling
spec:
  selector:
    matchLabels:
      run: test-node-auto-scaling
  replicas: 10
  template:
    metadata:
      labels:
        run: test-node-auto-scaling
    spec:
      containers:
      – name: test-node-auto-scaling
        image: k8s.gcr.io/hpa-example
        ports:
        – containerPort: 80
        resources:
          limits:
            cpu: 200m
          requests:
            cpu: 100m

2. Next, create the Deployment and check the pods created as part of the Deployment.
a. kubectl apply -f test-auto-scaling.yaml
b. kubectl get pods -A

Test the Kubernetes Cluster Autoscaler step 2

3. When you check the logs of the Kubernetes Autoscaler, you will notice that the autoscaler has detected that it is necessary to scale the nodes seeing as not all the pods fit in the current nodes.
a. kubectl -n kube-system logs -f deployment.apps/cluster-autoscaler

Test the Kubernetes Cluster Autoscaler step 3

4. Upon checking the number of nodes using the kubectl command, you will notice some newly added nodes, as required. In this case, 1 new node has been added. The same can be seen in the AWS EC2 Console
a. kubectl get nodes
b. kubectl get pods
c. kubectl get pods -o wide

Test the Kubernetes Cluster Autoscaler step 4
Test the Kubernetes Cluster Autoscaler step 4

5. Now, in order to test whether the Kubernetes Autoscaler reduced or removed the nodes, delete the Deployment you created.
a. kubectl get deployment
b. kubectl delete deployment test-node-auto-scaling
c. kubectl get pods

Test the Kubernetes Cluster Autoscaler step 5

6. Check the logs of the Kubernetes Autoscaler again, you will notice that the autoscaler has identified the unrequired nodes. Within a few minutes, it will also reduce the number of nodes.
a. kubectl -n kube-system logs -f deployment.apps/cluster-autoscaler

Test the Kubernetes Cluster Autoscaler step 6
Test the Kubernetes Cluster Autoscaler step 6
hire our top engineers to help you scale your app

Conclusion

Now you know exactly how Kubernetes Autoscaling can help you scale resources in and out on the Kubernetes Cluster. Keep in mind that both layers (nodes/pods) of the Kubernetes Autoscaling are important and interrelated.

You can leverage HPA to scale the number of pods in and out. More specifically, you can increase the pod count when consumption increases and decrease the pod count when user load decreases. HPA increases or decreases the pod count, whereas VPA automatically increases or decreases the CPU and memory reservations of the pods to help you “right-size” your applications.

HPA and VPA achieve Kubernetes Autoscaling at pod level. You need the Kubernetes Autoscaler to increase the number of nodes in the cluster.

Make sure you avoid using HPA and VPA together for the same set of pods seeing as HPA and VPA are currently incompatible and serve different purposes. However, we do recommend using VPA in combination with the Cluster Autoscaler (CA)

Whether you employ HPA, VPA, CA, or a mix will depend on the needs of your application. Experimentation is the best way to determine which choice is best for you, therefore it may take a few tests before you achieve your optimal  setup. Learning to work with Kubernetes Autoscaling is a journey that will require continual learning along the way as the tools mature.

FAQ

What is the Kubernetes Cluster Autoscaler?

The Kubernetes Cluster Autoscaler is a Kubernetes Autoscaling mechanism that helps increase or decrease the numbers of nodes in the Kubernetes Cluster depending on the resource requirements.

What is Kubernetes HPA?

Horizontal Pod Autoscaling scales the number of pods in the Kubernetes Cluster to match demand.

What is Kubernetes VPA?

Vertical Pod Autoscaling enables automatic CPU and memory requests and limits adjustments based on resource usage. Unlike HPA, VPA doesn’t increase or decrease the pod count.

What is the difference between Kubernetes HPA and VPA?

HPA increases or decreases the number of pods, whereas VPA increases or decreases the pod resources.

Subscribe

to our newsletter

Table of Contents
Weekly DevOps Newsletter

Subscribe to our DevOps News

Subscribe to a monthly newsletter to receive the IT best practices, startup-related insights & emerging technologies.

Join hundreds of business leaders and entrepreneurs, who are part of our growing tech community.

We guarantee 100% privacy. Your information will not be shared.
