There exist Slack integrations for everything but sometimes you need something more specific so this time I’m going to show you a way to create your own AWS Lambda CloudWatch customizable integration to be notified when your application logs something in CloudWatch.

A custom integration, what is it?

Incoming webhooks are a simple way to share information from external sources with your workspace. Slack Help Center

The API to create an integration is very complete, of course it depends on the things you want to create but it covers enough to solve all needs. On other hand, is a way to have total control under your information and the format used to display it in your Slack workspace.

What is a Lambda function?

Basically it is a code snippet that only runs on demand and the price is cheaper than other Slack integrations that you have to pay even if they are not used. Using this Lambda function you can reduce your costs a bit by eliminating unnecessary integrations since if you only need to send error alerts, the use of this function should be very little because of course, we do not want our applications in production to be full of errors.

We can help you manage and monitor your AWS Cloud resources & applications with our AWS Managed Services!

Let’s go to AWS Lambda CloudWatch Log

  1. First, you need to access to AWS Management Console

2. Create a new IAM role, it will be used to access to CloudWatchLogs events.

Create a new IAM role
Create a new IAM role
Create a new IAM role

3. Now you need to create 2 logs groups in CloudWatch/aws/lambda/Log2Slack and production-api or whatever name you want to test. Note: Retetion setting is used to assign a log lifetime

create log group in CloudWatch
create log group in CloudWatch

4. In order to create the lambda function, you need to go to Lambda and click on Create button then assign a name, select the runtime language (Node.js for this example) and assign the role previously created.

create the lambda function
create the lambda function

5. Add a trigger to listen to the CloudWatch events.

Add trigger
Add trigger

6. Before adding the lambda code you need to create a custom integration using this URL https://{your-slack-workspace}.slack.com/apps/manage/custom-integrations then clicking on Incoming Webhooks

7. Now click on Add to Slack

Add to Slack
  • Select a channel to post the alerts
  • Click on Add Incoming Webhook integration
  • Copy the value of Webhook URL  Note: _In Integration Settings you can assign a name and a logo to provide a nicer look _
  1. It has been a long road so far, but now you are very close to completing the integration, click on the name of your function to open the code editor and then double click on the index.js file and replace the current content with the code below.
replace the current content with the code
const zlib = require("zlib");
const https = require("https");
const SLACK_ENDPOINT =
  "/services/T1N6FE97Y/B01NK2BR2CR/TrCYV2mkCIRaaxopcXYF3jyc"; // don't use this endpoint, I removed it after publish this post
const SLACK_BOT = "Cloudwatch";

function doRequest(content) {
  // formatting the message according Slack API
  const payload = {
    username: SLACK_BOT,
    blocks: [
      {
        type: "header",
        text: {
          type: "plain_text",
          text: "Whoops, looks like something went wrong 😞🤕",
          emoji: true,
        },
      },
      {
        type: "section",
        fields: [
          {
            type: "mrkdwn",
            text: "<!here> the API is running into an issue",
          },
        ],
      },
      {
        type: "section",
        fields: [
          {
            type: "mrkdwn",
            text: "*Environment: * Production",
          },
        ],
      },
      {
        type: "section",
        fields: [
          {
            type: "mrkdwn",
            text: "*Message:* _" + content.message + "_",
          },
        ],
      },
      {
        type: "section",
        fields: [
          {
            type: "mrkdwn",
            text: "*Stacktrace:*",
          },
        ],
      },
      {
        type: "section",
        text: {
          type: "mrkdwn",
          text:
            "```" +
            JSON.stringify(content.original ? content.original : content) +
            "```",
        },
      },
      {
        type: "divider",
      },
    ],
  };

  const payloadStr = JSON.stringify(payload);
  const options = {
    hostname: "hooks.slack.com",
    port: 443,
    path: SLACK_ENDPOINT,
    method: "POST",
    headers: {
      "Content-Type": "application/json",
      "Content-Length": Buffer.byteLength(payloadStr),
    },
  };

  const postReq = https.request(options, function (res) {
    const chunks = [];
    res.setEncoding("utf8");
    res.on("data", function (chunk) {
      return chunks.push(chunk);
    });
    res.on("end", function () {
      if (res.statusCode < 400) {
        console.log("sent!!!");
      } else if (res.statusCode < 500) {
        console.error(
          "Error posting message to Slack API: " +
            res.statusCode +
            " - " +
            res.statusMessage
        );
      } else {
        console.error(
          "Server error when processing message: " +
            res.statusCode +
            " - " +
            res.statusMessage
        );
      }
    });
    return res;
  });
  postReq.write(payloadStr);
  postReq.end();
}

function main(event, context) {
  context.callbackWaitsForEmptyEventLoop = true;
  // always returns the last event
  const payload = Buffer.from(event.awslogs.data, "base64");
  const log = JSON.parse(zlib.gunzipSync(payload).toString("utf8"));
  // the log is an object that contains an array of events called `logEvents` and we need access it bypassing the index 0
  doRequest(log.logEvents[0]);
  const response = {
    statusCode: 200,
    body: JSON.stringify("Event sent to Slack!"),
  };
  return response;
}

exports.handler = main;
  1. Click on Deploy button to complete the function.
  2. Testing, testing and testing. There are two ways to test the function:
  • Clicking on Test button and selecting the Amazon Cloudwatch Logs template.
Click on Test button and select the Amazon Cloudwatch Logs template
  • Creating a Log Stream directly into the Log Group , then enter to log stream and triggering a log event manually.
Creating a Log Stream
Creating a Log Stream

This is the final result after a Cloudwatch log is sent to Slack 🎉

AWS Lambda CloudWatch Log custom integration for Slack

Slack resources:

Do you need an expert engineer to help you solve your software development challenges? Here we are! Just contact us!

Final thoughts

Create your own AWS Lambda CloudWatch integration to log the relevant information about your applications is very easy and if you want you can customize each type of log level to show as successinfowarning or error providing an easy way to fix the issues without wasting time checking the logs directly in Cloudwatch.
